Heat pump for hot tubs and NORM MINI CUBE swim spa pools
With its compact dimensions and performance, the Norm MINI CUBE is suitable for use with small private pools, whirlpool hot tubs and swim spa pools.
It can be controlled remotely using a smartphone (Bluetooth) via the “AQUA TEMP” app
- C.O.P. up to 4,9
- The heat pump can be controlled via Bluetooth
- Operating temperature: +10 to +43 °C
- Connection:
- 32/38 mm hose barb
- 32-50 mm union fitting
- For small hot tubs, swim spa pools and whirlpools
Technical specifications
| Product type: | Heat pump for hot tubs and swim spa pools. |
|---|---|
| Colour: | Dark grey |
| Heating capacity: | 3,5 kW |
| Cooling: | No |
| Recommended pool volume: | max. 15 m3 |
| Connection: | 32/38 mm |
| Refrigerant used: | R32 |
| Voltage: | 230 V |
| Efficiency: | 4,9 C.O.P. |
| Net/shipping weight kg: | 23 kg |
| Net unit dimensions (w/l/h): | 400 x 400 x 420 mm |
| Power input: | 0,72 kW |
| Noise level: | 46 dB |
| Operating temperature: | +10 to +43 °C |
| Output: | 3,5 kW |
| Recommended water flow: | 1,5 m3/h |
| Digital control panel: | Yes |
Logistics
| Weight: | 31 kg |
|---|---|
| In group packaging: | 1 |
| On a pallet: | 0 |
